This refractometer is designed for fast and accurate determination of the battery electrolyte condition, isopropanol-based (IPA) windscreen washer fluids freezing point, ethylene glycol-based coolants freezing point and propylene glycol-based coolants freezing point.
Price tip: an affordable alternative to digital refractometer is the optical refractometer RBC4AB-ATC.
| Scale | Scale range | Resolution |
| Ethylene glycol-based mixture VW |
0 to -50 °C |
0.1 °C |
| Propylene glycol-based mixture VW |
0 to -50 °C |
0.1 °C |
| Battery electrolyte |
1.00 to 1.50 kg/l |
0.01 kg/l |
| Isopropanol-based windscreen washer fluids |
0 to -40 °C |
0.1 °C |
The measurement
The liquids measuring is very easy. By holding down the button "Cal" and repeatedly pressing the button "Meas" we choose a measuring scale. Place a few drops of the measured liquid on the cleaned sensor, press once the button "Meas" and the result value will be showed on the display.
General technical specifications
- ATC - automatic temperature compensation: 5 to 40 °C (41 to 104 °F)
- Min. sample volume: 0.3 ml
- Measuring time: ≤ 3 s
- Power source: 2 AAA batteries (batteries are not included)
- Battery life: ≥ 2000 readings
- Dimensions: 135 x 65 x 40 mm
- Weight: 200 g
- Package contents: transport case, leatherette carrying bag, refractometer, cleaning cloth, plastic pipette, operating instructions in English
